ProductsSelf Propelled Order Picker 136kg Cap 3m height
Self Propelled Order Picker SP50
Self Propelled Order Picker SP50
Self Propelled Aerial Order Picker SP50
Aerial Order PickerPopularPremiumNewRecommended

Self Propelled Order Picker 136kg Cap 3m height

1. Carrying one person with weight less than 136kg capacity up to 3.1m height. 2. Lifting goods less than 90kgs load tray capacity from 41.3" to 149.5" in height 3. Cargo with weight less than 240 lbs load deck for powered cargo shelf, 200 lbs for chassis shelf. 4. Electric move, Electric lift, 2 × 12 V/150 Ah battery, free maintenance. 5. 110-220 V Build-in charger solution, 8 hrs charging time 6. Turning radius: 55’’ , 15% Grade-ability 7. Wheel type: Non-marking, Anti-Skid Solid Rubber 8. Drive motor: 0.8-1.2 KW, Driving speed: from 1 to 3.36 mph with choice. 9. Product weight: 1180 lbs (520kgs) 10. Ground clearance: 57mm

Contact Us
⭐ New Generation | Self Propelled
SP50 Self Propelled Electric Order Picker
Model: SP50 | 136kg Operator Capacity | 3.1m Platform Height. SP50 is a compact, self-propelled electric order picker engineered for efficient warehouse picking operations. With 5.1m working height, intelligent driving system, and durable aluminum alloy mast, it delivers precision, safety, and productivity in narrow aisle environments.
⚡ Electric 24V DC🔄 Self-Propelled🛡️ Intelligent Steering Return🔋 300 Lifts / 10km drive📦 Multi-Shelf Capacity
✔ ISO9001 & CE Certified | OEM & Customization Available | Global Shipping

Why Choose SP50 Order Picker

🏗️

High-Strength Aluminum Alloy Mast

Aircraft-grade aluminum alloy elevating mechanism ensures exceptional rigidity, minimal oscillation, and smooth lifting/lowering for maximum stability at height.
🔄

Active Front Steering + Rear Bridge Drive

Active front steering combined with rear bridge drive structure effectively prevents loss of direction, maintaining superior walking performance even on uneven ground.
🧠

Intelligent Driving Assistance

Steering wheel automatically returns to center when released, reducing operator actions and enabling faster, more intuitive control with less fatigue.
🎛️

Ergonomic Proportional Control

Proportional valve handles provide precise, effortless driving and lifting control—ideal for long shifts and high-frequency operations.
💡

LED Auxiliary Work Lights

Built-in LED lights provide supplementary illumination for low-light work environments and nighttime warehouse operations.
🧰

Removable Tool Box

Convenient detachable tool box for storing common tools and accessories, enhancing on-the-job efficiency and organization.

Complete Technical Specifications

Model
SP50
📐 DIMENSIONS
Max. Platform Height
3100mm (3.1m)
Max. Working Height
5100mm (5.1m)
Platform Size (L×W)
696mm × 564mm
Platform Entry Height
350mm
Occupants (Platform)
1 person
Stowed Length × Width × Height
1595mm × 750mm × 1528mm
Machine Weight (Reference)
520kg
⚖️ LOAD CAPACITIES
Operator Compartment Capacity
136kg (300 lbs)
Powered Cargo Shelf Capacity
90kg
Ground Cargo Shelf Capacity
115kg
🚀 PERFORMANCE
Moving Method
Self Propelled (Electric Drive)
Drive Speed (Level 1/2/3)
5.4 km/h / 3.2 km/h / 1.6 km/h
Driving System
Proportional Control
Platform Cycle Performance
Raise: 18 sec / Lower: 20 sec
Max. Steering Angle
80°
Turning Radius (Outside / Inside)
1.8m / ~0m
Climb Ability
15% grade
Max. Allowed Wind Speed
12.5 m/s
Rated Oil Pressure
10 MPa
Maximum Horizontal Lateral Force
200 Newtons
Tires
Non-marking, Anti-Skid Solid Rubber
Battery Durable Time
300 lifting cycles or 10km driving distance
🔋 POWER SOURCE
Power Supply
DC 24V
Power Input
0.8 – 1.2 kW
Battery
12V / 150Ah × 2 pieces (24V system)
Recharge Power Supply
220V AC or 110V AC (Dual Voltage Compatible)
* Specifications are subject to change without notice. Contact Outstrip for latest updates.
